| Model | SX425844344C |
| Make | SHACMAN |
| Drive type | 6×4 |
| Weight | |
| Complete kerb mass(kg) | 8,900 |
| GCW(kg) | 49,000 |
| Dimensions | |
| Max.length(mm) | 7,025 |
| Max.width(mm) | 2,490 |
| Max.height(mm) | 3,980 |
| Wheel base(mm) | 3,375+1,400 |
| Performance | |
| Max.speed(km/h) | 105 |
| Max.gradeability(%) | 20 |
| Engine | |
| Make | CUMMINS |
| Model | M13E5 560 |
| Power(hp) | 412/560 |
| Max. torque(N.m/rpm) | 2,600/900~1,400 |
| Rated speed(r/min) | 1,800 |
| Displacement(ml) | 12,500 |
| Emission Standard | E-V |
| Transmission | |
| Make | FAST GEAR |
| Model | SF16JZ260A |
| Type | AMT with overdrive |
| Gear Shift | 16 forward and 2 reverse |
| Ratio | F: 14.129 11.703 9.766 8.089 6.685 5.537 4.521 3.745 3.125 2.588 2.160 1.789 1.479 1.225 1.000 0.828 R: 12.999 10.767 |
| PTO | QHG50C |
| Retarder | |
| Make | FAST GEAR |
| Model | FHB400 |
| Type | Hydraulic retarder, in parallel |
| Brakes | |
| Type | Drum |
| Service brake | With dual-circuit compressed air brake |
| Park brake | Power spring brake acting on rear wheel |
| Auxiliary brake | JACOB |
| WABCO ABS with 6 channels | |
| Steering | |
| Type | ZF technology, integral inner circulation power steering |
| Chassis | |
| Frame | (970-850)*270, with single layer |
| Suspension | |
| Front Suspension | Semi-elliptic leaf springs |
| Rear Suspension | Pneumatic suspension with 8 airbags with ECAS |
| Axles | |
| Make | HANDE |
| Front axle | MAN 7,500kg |
| Rear axle | MAN 11,500kg × 2= 23,000kg driven axles |
| Single reduction driven axles with inter-wheel differential and differential lock without hub reductor | |
| Ratio | 4.111 |
| Tyre | |
| Model | Front Tyre 12R22.5*2 Rear Tyre 425/65R22.5*4 Spare Tyre 425/65R22.5*1 |
| Rim | Aluminium |
| Fuel tank | |
| Tank capacity(L) | 600+230 |
| Material | Aluminium |
| Cabin | |
| Type | X5000, Lengthened high roof |
| Equipments | Cabin with spoilers, Cabin with pneumatic suspension, Cabin with clerestory, A/C, Rear window, Electronica heated rear mirrors, Electronica windows lifting system, Multi-media LED screen, Multi-functional steering wheel with cruise control switch, Driver and co-pilot seat with pneumatic suspension, Electronica reversal cabin, Radio with MP3 format, Central lock, LED daytime running lights, 2kg fire extinguisher. |
| Fifth wheel | JOST 50# |
| Others | Fleetguard air filter, Reversing buzzer, Aluminium air reservoirs, Rear bumper. |
