| Model | SX5255GJBJR384 |
| Max. running speed(km/h) | 85 |
| Drive System | 8× 4 |
| Kerb weight(kg) | 12000 |
| Total mass(kg) | 25000 |
| Overall dimensions (mm) | Length | 9135 |
| Width | 2500 |
| Height | 3774 |
| Capability (CBM) | 15 |
| Tank material | Q345/520JJ |
| Wheel base (mm) | 3775+1400 |
| Engine | WP10.375+PTO, Weichai engine Euro 2 |
| Rated output horsepower | 375hp |
| Cab | F3000 lengthened Cabin with A/C |
| Gearbox | RTD11509C |
| Reducer | TOPUIONP68 Italy |
| Oil Pump | EATON |
| Motor | EATON |
| Feeding Speed (m3/min) | ≥3 |
| Discharge Rate (m3/min) | ≥2.5 |
| Discharge Residual Rate (%) | ≤1 |
| Water Supply System | Air pressure water supply |
| Water Tank Volume (L) | 450 |
| Axle | 16 Ton double reduction-gear axle, ratio 5.92 |
| Tyre(RADIAL TYRE) | 12.00R20 |
